Product Summary
The LTST-C17FB1WT is ultra bright AlInGaP chip LED.
Parametrics
Absolute maximum ratings: (1)power dissipation: 100 mW; (2)peak forward current: 200 mA; (3)continuous forward current: 40 mA; (4)derating linear from 50 鈩? 0.8 mA/鈩? (5)reverse voltage: 5V; (6)operating temperature range: -55 to +85鈩? (7)storage temperature range: -55 to +85鈩? (8)wave soldering condition: 260 鈩?for 5 seconds; (9)infrared soldering condition: 260 鈩?for 5 seconds; (10)vapor phase soldering condition: 215 鈩?for 3 minutes.
Features
Features: (1)package in 7" diameter reels; (2)compatible with automatic placement equipment; (3)compatible with infrared and vapor phase reflow solder process; (4)EIA STD package; (5)I.C. compatible.
Diagrams
<IMG src="http://www.seekic.com/uploadfile/ic-mfg/2011426224650591.jpg" border=0>
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LTST-C17FB1WT |
Lite-On |
Standard LED - SMD RGB Diffused |
Data Sheet |
|
|
||||||||||
