Product Summary
The KMC7D0CN20CA is a Common N-Ch Trench MOSFET with low drain-source on resistance, esd protection, super high dense cell design. It is used in switching regulator and DC-DC Converter applications. The KMC7D0CN20CA is mainly suitable for Li-ion battery pack. Its drain-source voltage, VDSS is 20 V. Its drain current is ID *= 7 A at DC; Pulsed IDP *=28. What is more, Its drain power dissipation at Ta = 25℃, PD * is 1.5 W.
Parametrics
Absolute maximum ratings:(1)Drain-Source Voltage, VDSS: 20 V ; (2)Gate-Source Voltage, VGSS: +12 V ; (3)Drain Current: DC ID *= 7 A; Pulsed IDP *=28 ; (4)Source-Drain Diode Current, IS * :1.7 A ; (5)Drain Power Dissipation at Ta = 25℃, PD *: 1.5 W ; (6)Maximum Junction Temperature, Tj: 150 ℃ ; (7)Storage Temperature Range, Tstg: -55 150 ℃ ; (8)Thermal Resistance, Junction to Ambient, RthJA*: 83.3 ℃/W.
Features
Features: (1)VDSS=20V, ID=7A; (2)Low Drain-Source On Resistance: RDS(ON)=20.5m (Max.) @ VGS=4.5V; RDS(ON)=21.0m (Max.) @ VGS=4.0V; RDS(ON)=22.5m (Max.) @ VGS=3.1V; RDS(ON)=26.0m (Max.) @ VGS=2.5V; (3)ESD Protection; (4)Super High Dense Cell Design.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 KMC7D0CN20CA |
Other |
|
Data Sheet |
Negotiable |
|
||||||
